Circulation Heater )

Name: Circulation Heater )
Brand: INTEGRO ENGINEERS PVT. LTD.
Price: 350000.0 INR
Availability: InStock

Price 350000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Nos

Circulation Heater ) Specification

Heating Element
High Grade Nickel Chrome

Mounting Type
Flanged / Threaded

Usage
Industrial Fluid Heating

Voltage
230 V

Application Areas
Water, Oil, Chemicals Heating

Temperature
Up to 300C

Frequency
50 Hz

Diameter
100 mm

Features
Efficient Heating, Robust Construction, Easy Maintenance

Phase
Single / Three Phase

Terminal Type
Screw Terminal

Material Specified
Mild Steel

Insulation Material
Ceramic Wool

Shape
Cylindrical

Power
5 kW

Lead Wire Length
1 Meter Standard

Control Panel
Optional Digital/Analog

Surface Finish
Powder Coated / Painted

Operating Pressure
Up to 10 Bar

Connection Size
1" BSP to 3" BSP

Protection Class
IP55

Thermocouple Provision
Yes

Flow Direction
Horizontal / Vertical

Circulation Heater ) Trade Information

Minimum Order Quantity
1 Nos

Supply Ability
2 Per Day

Delivery Time
1 Days

Sample Available
Yes

Certifications
CE

About Circulation Heater )

Circulation heaters, as used for indirect heating, are specialized heating devices that heat fluids flowing through a closed-loop system. They are widely used in various industries requiring precise and efficient heating. The primary purpose of circulation heaters is to maintain the desired fluid temperature during circulation, ensuring optimal process conditions and preventing issues such as viscosity changes crystallization, or freezing.

Type and Range:

Single stage or multiple stage
Ranging from 25KW to 500KW
With PLC control or compatible with BMS
Electrical/ steam/hot oil options available.

Reliable Industrial Fluid Heating

Designed to handle demanding environments, the Circulation Heater offers efficient and precise temperature control for water, oil, and chemical heating tasks. Its robust construction, combined with high-grade materials and ceramic wool insulation, guarantees optimal performance under pressures up to 10 Bar and temperatures up to 300C.

Versatile Installation and Control Options

With mounting choicesflanged or threadedand adaptability for both horizontal and vertical flow directions, this heater fits seamlessly into a variety of industrial setups. Operators can choose between digital and analog control panels to suit their management preferences, ensuring easy system integration and adjustment.

FAQs of Circulation Heater ):

Q: How does the Circulation Heater maintain efficient heating in industrial applications?

A: The Circulation Heater utilizes a high-grade nickel chrome element and ceramic wool insulation to provide rapid and consistent heating. Its design allows for even heat distribution in fluids like water, oil, or chemicals, ensuring energy efficiency and reliable temperature control up to 300C.

Q: What control options are available for this Circulation Heater and how do they enhance usability?

A: Operators have the choice of an optional digital or analog control panel, making it easy to monitor and adjust heating parameters based on specific process requirements. This flexibility enhances usability and process control in various industrial settings.

Q: When should I use a flanged vs. a threaded mounting for this Circulation Heater?

A: Select a flanged mounting for larger systems or where frequent maintenance is expected, as it provides secure attachment and easier removal. Threaded mounting is ideal for smaller setups or applications requiring compact installations.

Q: Where is this Circulation Heater commonly applied?

A: This heater is widely used across industries in India for heating fluids such as water, oil, and chemicals. Typical applications include process heating, pre-heating, and maintaining fluid temperatures within industrial systems.

Q: What is the process for installing the Circulation Heater in a fluid heating system?

A: Begin by choosing the appropriate mounting typeflanged or threadedbased on your piping arrangement. Install the heater in the desired flow orientation (horizontal or vertical), connect to power (single or three-phase, 230 V), and use the provided screw terminals. Ensure the thermocouple is properly placed to monitor temperature, and select your preferred control panel if needed.

Q: What are the main benefits of using this Circulation Heater?

A: Key benefits include efficient and uniform heating, robust construction for long-term reliability, minimal maintenance due to high-quality materials, and versatility in installation and control configurations. Its IP55 protection ensures safe operation in industrial environments.
